Initial Investment and Pricing Models

In 1839, the ability of some materials to create an electrical charge from light exposure was first observed by the French physicist Edmond Becquerel.^[2] Though these initial solar panels were too inefficient for even simple electric devices, they were used as an instrument to measure light.^[3]

The observation by Becquerel was not replicated again until 1873, when the English electrical engineer Willoughby Smith discovered that the charge could be caused by light hitting selenium. After this discovery, William Grylls Adams and Richard Evans Day published "The action of light on selenium" in 1876, describing the experiment they used to replicate Smith's results.^[2][4]

In 1881, the American inventor Charles Fritts created the first commercial solar panel, which was reported by Fritts as "continuous, constant and of considerable force not only by exposure to sunlight but also to dim, diffused daylight".^{[5][6][clarification needed]} However, these solar panels were very inefficient, especially compared to coal-fired power plants.

In 1939, Russell Ohl created the solar cell design that is used in many modern solar panels. He patented his design in 1941.^[7] In 1954, this design was first used by Bell Labs to create the first commercially viable silicon solar cell.^[2]

Solar panel installers saw significant growth between 2008 and 2013.^[8] Due to that growth many installers had projects that were not "ideal" solar roof tops to work with and had to find solutions to shaded roofs and orientation difficulties.^[9] This challenge was initially addressed by the re-popularization of micro-inverters and later the invention of power optimizers.

Solar panel manufacturers partnered with micro-inverter companies to create AC modules and power optimizer companies partnered with module manufacturers to create smart modules.^[10] In 2013 many solar panel manufacturers announced and began shipping their smart module solutions.^[11]

Photovoltaic modules consist of a large number of solar cells and use light energy (photons) from the Sun to generate electricity through the photovoltaic effect. Most modules use wafer-based crystalline silicon cells or thin-film cells. The structural (load carrying) member of a module can be either the top layer or the back layer. Cells must be protected from mechanical damage and moisture. Most modules are rigid, but semi-flexible ones based on thin-film cells are also available. The cells are usually connected electrically in series, one to another to the desired voltage, and then in parallel to increase current. The power (in watts) of the module is the voltage (in volts) multiplied by the current (in amperes), and depends both on the amount of light and on the electrical load connected to the module. The manufacturing specifications on solar panels are obtained under standard conditions, which are usually not the true operating conditions the solar panels are exposed to on the installation site.^[12]

A PV junction box is attached to the back of the solar panel and functions as its output interface. External connections for most photovoltaic modules use MC4 connectors to facilitate easy weatherproof connections to the rest of the system. A USB power interface can also be used.^[13] Solar panels also use metal frames consisting of racking components, brackets, reflector shapes, and troughs to better support the panel structure.^[14]

Solar modular cells need to be connected together to form the module, with front electrodes blocking the solar cell front optical surface area slightly. To maximize frontal surface area available for sunlight and improve solar cell efficiency, manufacturers use varying rear electrode solar cell connection techniques:

• Passivated emitter rear contact (PERC) uses aluminum rear contact face and adds a polymer film to capture light^[15]
• Tunnel oxide passivated contact (TOPCon) uses increasingly smaller silver rear bus bars and adds an oxidation layer to the PERC film to capture more light^[16][17][18]
• Interdigitated back contact (IBC)^[19]

A single solar module can produce only a limited amount of power; most installations contain multiple modules adding their voltages or currents. A photovoltaic system typically includes an array of photovoltaic modules, an inverter, a battery pack for energy storage, a charge controller, interconnection wiring, circuit breakers, fuses, disconnect switches, voltage meters, and optionally a solar tracking mechanism. Equipment is carefully selected to optimize energy output and storage, reduce power transmission losses, and convert from direct current to alternating current.

Smart modules are different from traditional solar panels because the power electronics embedded in the module offers enhanced functionality such as panel-level maximum power point tracking, monitoring, and enhanced safety.^[20] Power electronics attached to the frame of a solar module, or connected to the photovoltaic circuit through a connector, are not properly considered smart modules.^[21]

Several companies have begun incorporating into each PV module various embedded power electronics such as:

• Maximum power point tracking (MPPT) power optimizers, a DC-to-DC converter technology developed to maximize the power harvest from solar photovoltaic systems by compensating for shading effects, wherein a shadow falling on a section of a module causes the electrical output of one or more strings of cells in the module to fall to near zero, but not having the output of the entire module fall to zero.^[22]
• Solar performance monitors for data and fault detection

Most solar modules are currently produced from crystalline silicon (c-Si) solar cells made of polycrystalline or monocrystalline silicon. In 2021, crystalline silicon accounted for 95% of worldwide PV production,^[23][24] while the rest of the overall market is made up of thin-film technologies using cadmium telluride (CdTe), copper indium gallium selenide (CIGS) and amorphous silicon (a-Si).^[25]

Emerging, third-generation solar technologies use advanced thin-film cells. They produce a relatively high-efficiency conversion for a lower cost compared with other solar technologies. Also, high-cost, high-efficiency, and close-packed rectangular multi-junction (MJ) cells are usually used in solar panels on spacecraft, as they offer the highest ratio of generated power per kilogram lifted into space. MJ-cells are compound semiconductors and made of gallium arsenide (GaAs) and other semiconductor materials. Another emerging PV technology using MJ-cells is concentrator photovoltaics (CPV).

Some special solar PV modules include concentrators in which light is focused by lenses or mirrors onto smaller cells. This enables the cost-effective use of highly efficient, but expensive cells (such as gallium arsenide) with the trade-off of using a higher solar exposure area.^[29] Concentrating the sunlight can also raise the efficiency to around 45%.^[30]

The amount of light absorbed by a solar cell depends on the angle of incidence of whatever direct sunlight hits it. This is partly because the amount falling on the panel is proportional to the cosine of the angle of incidence, and partly because at high angle of incidence more light is reflected. Modules usually are faced south (in the Northern Hemisphere) or north (in the Southern Hemisphere) with a particular tilt calculated according to the latitude, to maximize total energy output over a day. Solar tracking can be used to adjust the tilt angle from dawn to dusk, to keep the angle of incidence small.

Solar panels are often coated with an anti-reflective coating, using one or more thin layers of substances with refractive indices intermediate between that of silicon and that of air, causing destructive interference of the reflected light. Photovoltaic manufacturers have been working to decrease reflectance with improved anti-reflective coatings or with textured glass.^[31][32]

In general with individual solar panels, if not enough current is taken, then power isn't maximised. If too much current is taken then the voltage collapses. The optimum current draw is roughly proportional to the amount of sunlight striking the panel. Solar panel capacity is specified by the MPP (maximum power point) value of solar panels in full sunlight.

Solar inverters convert the DC power provided by panels to AC power.

MPP (Maximum power point) of the solar panel consists of MPP voltage (V_mpp) and MPP current (I_mpp). Performing maximum power point tracking (MPPT), a solar inverter samples the output (I-V curve) from the solar cell and applies the proper electrical load to obtain maximum power.

An AC (alternating current) solar panel has a small DC to AC microinverter on the back and produces AC power with no external DC connector. AC modules are defined by Underwriters Laboratories as the smallest and most complete system for harvesting solar energy.^[33][34]

Micro-inverters work independently to enable each panel to contribute its maximum possible output for a given amount of sunlight, but can be more expensive.^[35]

Module electrical connections are made with conducting wires that take the current off the modules and are sized according to the current rating and fault conditions, and sometimes include in-line fuses.

Panels are typically connected in series of one or more panels to form strings to achieve a desired output voltage, and strings can be connected in parallel to provide the desired current capability (amperes) of the PV system.

In string connections the voltages of the modules add, but the current is determined by the lowest performing panel. This is known as the "Christmas light effect". In parallel connections the voltages will be the same, but the currents add. Arrays are connected up to meet the voltage requirements of the inverters and to not greatly exceed the current limits.

Blocking and bypass diodes may be incorporated within the module or used externally to deal with partial array shading, in order to maximize output. For series connections, bypass diodes are placed in parallel with modules to allow current to bypass shaded modules which would otherwise severely limit the current. For paralleled connections, a blocking diode may be placed in series with each module's string to prevent current flowing backwards through shaded strings thus short-circuiting other strings. If three or more strings are connected in parallel, fuses are generally included on each string to eliminate the possibility of diode failures overloading the panels and wiring and causing fires.

Outdoor solar panels usually include MC4 connectors, automotive solar panels may include an auxiliary power outlet and/or USB adapter and indoor panels may have a microinverter.



Each module is rated by its DC output power under standard test conditions (STC) and hence the on field output power might vary. Power typically ranges from 100 to 365 Watts (W). The efficiency of a module determines the area of a module given the same rated output – an 8% efficient 230 W module will have twice the area of a 16% efficient 230 W module. Some commercially available solar modules exceed 24% efficiency.^[37][38] As of 2025,^[39] the best achieved sunlight conversion rate (solar module efficiency) is around 24.5% in new commercial products^[40] typically lower than the efficiencies of their cells in isolation. The most efficient mass-produced solar modules have power density values of up to 175 W/m² (16.22 W/ft²).^[41]

The current versus voltage curve of a module provides useful information about its electrical performance.^[42] Manufacturing processes often cause differences in the electrical parameters of different modules photovoltaic, even in cells of the same type. Therefore, only the experimental measurement of the I–V curve allows us to accurately establish the electrical parameters of a photovoltaic device. This measurement provides highly relevant information for the design, installation and maintenance of photovoltaic systems. Generally, the electrical parameters of photovoltaic modules are measured by indoor tests. However, outdoor testing has important advantages such as no expensive artificial light source required, no sample size limitation, and more homogeneous sample illumination.

Capacity factor of solar panels is limited primarily by geographic latitude and varies significantly depending on cloud cover, dust, day length and other factors. In the United Kingdom, seasonal capacity factor ranges from 2% (December) to 20% (July), with average annual capacity factor of 10–11%, while in Spain the value reaches 18%.^[43] Globally, capacity factor for utility-scale PV farms was 16.1% in 2019.^{[44][unreliable source?]}

Overheating is the most important factor for the efficiency of the solar panel.^[45]

Depending on construction, photovoltaic modules can produce electricity from a range of frequencies of light, but usually cannot cover the entire solar radiation range (specifically, ultraviolet, infrared and low or diffused light). Hence, much of the incident sunlight energy is wasted by solar modules, and they can give far higher efficiencies if illuminated with monochromatic light. Therefore, another design concept is to split the light into six to eight different wavelength ranges that will produce a different color of light, and direct the beams onto different cells tuned to those ranges.^[46]

Module performance is generally rated under standard test conditions (STC): irradiance of 1,000 W/m², solar spectrum of AM 1.5 and module temperature at 25 °C.^[47] The actual voltage and current output of the module changes as lighting, temperature and load conditions change, so there is never one specific voltage at which the module operates. Performance varies depending on geographic location, time of day, the day of the year, amount of solar irradiance, direction and tilt of modules, cloud cover, shading, soiling, state of charge, and temperature. Performance of a module or panel can be measured at different time intervals with a DC clamp meter or shunt and logged, graphed, or charted with a chart recorder or data logger.

For optimum performance, a solar panel needs to be made of similar modules oriented in the same direction perpendicular to direct sunlight. Bypass diodes are used to circumvent broken or shaded panels and optimize output. These bypass diodes are usually placed along groups of solar cells to create a continuous flow.^[48]

Electrical characteristics include nominal power (P_MAX, measured in W), open-circuit voltage (V_OC), short-circuit current (I_SC, measured in amperes), maximum power voltage (V_MPP), maximum power current (I_MPP), peak power, (watt-peak, W_p), and module efficiency (%).

Open-circuit voltage or V_OC is the maximum voltage the module can produce when not connected to an electrical circuit or system.^[49] V_OC can be measured with a voltmeter directly on an illuminated module's terminals or on its disconnected cable.

The peak power rating, W_p, is the maximum output under standard test conditions (not the maximum possible output). Typical modules, which could measure approximately 1 by 2 metres (3 ft × 7 ft), will be rated from as low as 75 W to as high as 600 W, depending on their efficiency. At the time of testing, the test modules are binned according to their test results, and a typical manufacturer might rate their modules in 5 W increments, and either rate them at +/- 3%, +/-5%, +3/-0% or +5/-0%.^[50][51][52]

The performance of a photovoltaic (PV) module depends on the environmental conditions, mainly on the global incident irradiance G in the plane of the module. However, the temperature T of the p–n junction also influences the main electrical parameters: the short circuit current I_SC, the open circuit voltage V_OC and the maximum power P_max. In general, it is known that V_OC shows a significant inverse correlation with T, while for I_SC this correlation is direct, but weaker, so that this increase does not compensate for the decrease in V_OC. As a consequence, P_max decreases when T increases. This correlation between the power output of a solar cell and the working temperature of its junction depends on the semiconductor material, and is due to the influence of T on the concentration, lifetime, and mobility of the intrinsic carriers, i.e., electrons and gaps. inside the photovoltaic cell.

Temperature sensitivity is usually described by temperature coefficients, each of which expresses the derivative of the parameter to which it refers with respect to the junction temperature. The values of these parameters can be found in any data sheet of the photovoltaic module; are the following:

- β: V_OC variation coefficient with respect to T, given by ∂V_OC/∂T.

- α: Coefficient of variation of I_SC with respect to T, given by ∂I_SC/∂T.

- δ: Coefficient of variation of P_max with respect to T, given by ∂P_max/∂T.

Techniques for estimating these coefficients from experimental data can be found in the literature^[53]

Studies have shown that while high temperatures negatively impact efficiency, colder temperatures can improve solar panel performance due to reduced electrical resistance within the cells. However, winter conditions introduce additional challenges such as snow accumulation and reduced daylight hours, which can offset the efficiency benefits of lower temperatures. Solar panels are still capable of generating power in winter, but overall output may be lower due to limited sunlight exposure and potential obstructions.^[54]

The ability of solar modules to withstand damage by rain, hail, heavy snow load, and cycles of heat and cold varies by manufacturer, although most solar panels on the U.S. market are UL listed, meaning they have gone through testing to withstand hail.^[55]

Potential-induced degradation (also called PID) is a potential-induced performance degradation in crystalline photovoltaic modules, caused by so-called stray currents.^[56] This effect may cause power loss of up to 30%.^[57]

Advancements in photovoltaic technologies have brought about the process of "doping" the silicon substrate to lower the activation energy thereby making the panel more efficient in converting photons to retrievable electrons.^[58]

Chemicals such as boron (p-type) are applied into the semiconductor crystal in order to create donor and acceptor energy levels substantially closer to the valence and conductor bands.^[59] In doing so, the addition of boron impurity allows the activation energy to decrease twenty-fold from 1.12 eV to 0.05 eV. Since the potential difference (E_B) is so low, the boron is able to thermally ionize at room temperatures. This allows for free energy carriers in the conduction and valence bands thereby allowing greater conversion of photons to electrons.

The power output of a photovoltaic (PV) device decreases over time. This decrease is due to its exposure to solar radiation as well as other external conditions. The degradation index, which is defined as the annual percentage of output power loss, is a key factor in determining the long-term production of a photovoltaic plant. To estimate this degradation, the percentage of decrease associated with each of the electrical parameters. The individual degradation of a photovoltaic module can significantly influence the performance of a complete string. Furthermore, not all modules in the same installation decrease their performance at exactly the same rate. Given a set of modules exposed to long-term outdoor conditions, the individual degradation of the main electrical parameters and the increase in their dispersion must be considered. As each module tends to degrade differently, the behavior of the modules will be increasingly different over time, negatively affecting the overall performance of the plant.^[60]

There are several studies dealing with the power degradation analysis of modules based on different photovoltaic technologies available in the literature. According to a recent study,^[61] the degradation of crystalline silicon modules is very regular, oscillating between 0.8% and 1.0% per year.

On the other hand, if we analyze the performance of thin-film photovoltaic modules, an initial period of strong degradation is observed (which can last several months and even up to 2 years), followed by a later stage in which the degradation stabilizes, being then comparable to that of crystalline silicon.^[62] Strong seasonal variations are also observed in such thin-film technologies because the influence of the solar spectrum is much greater. For example, for modules of amorphous silicon, micromorphic silicon or cadmium telluride, we are talking about annual degradation rates for the first years of between 3% and 4%.^[63] However, other technologies, such as CIGS, show much lower degradation rates, even in those early years.

Large utility-scale solar power plants frequently use ground-mounted photovoltaic systems. Their solar modules are held in place by racks or frames that are attached to ground-based mounting supports.^[64][65] Ground based mounting supports include:

• Pole mounts, which are driven directly into the ground or embedded in concrete.
• Foundation mounts, such as concrete slabs or poured footings
• Ballasted footing mounts, such as concrete or steel bases that use weight to secure the solar module system in position and do not require ground penetration. This type of mounting system is well suited for sites where excavation is not possible such as capped landfills and simplifies decommissioning or relocation of solar module systems.

Vertical bifacial solar cells are oriented towards east and west to catch the sun's irradiance more efficiently in the morning and evening. Applications include agrivoltaics, solar fencing, highway and railroad noise dampeners and barricades.^[66]

Roof-mounted solar power systems consist of solar modules held in place by racks or frames attached to roof-based mounting supports.^[67] Roof-based mounting supports include:

• Rail mounts, which are attached directly to the roof structure and may use additional rails for attaching the module racking or frames.
• Ballasted footing mounts, such as concrete or steel bases that use weight to secure the panel system in position and do not require through penetration. This mounting method allows for decommissioning or relocation of solar panel systems with no adverse effect on the roof structure.
• All wiring connecting adjacent solar modules to the energy harvesting equipment must be installed according to local electrical codes and should be run in a conduit appropriate for the climate conditions

Solar canopies are solar arrays which are installed on top of a traditional canopy. These canopies could be a parking lot canopy, carport, gazebo, Pergola, or patio cover.

There are many benefits, which include maximizing the space available in urban areas while also providing shade for cars. The energy produced can be used to create electric vehicle (EV) charging stations.^[68]

Portable solar panels can ensure electric current, enough to charge devices (mobile, radio, ...) via USB-port or to charge a powerbank f.e.

Special features of the panels include high flexibility, high durability & waterproof characteristics. They are good for travel or camping.

Solar trackers increase the energy produced per module at the cost of mechanical complexity and increased need for maintenance. They sense the direction of the Sun and tilt or rotate the modules as needed for maximum exposure to the light.^[69][70]

Alternatively, fixed racks can hold modules stationary throughout the day at a given tilt (zenith angle) and facing a given direction (azimuth angle). Tilt angles equivalent to an installation's latitude are common. Some systems may also adjust the tilt angle based on the time of year.^[71]

On the other hand, east- and west-facing arrays (covering an east–west facing roof, for example) are commonly deployed. Even though such installations will not produce the maximum possible average power from the individual solar panels, the cost of the panels is now usually cheaper than the tracking mechanism and they can provide more economically valuable power during morning and evening peak demands than north or south facing systems.^[72]

Solar panel conversion efficiency, typically in the 20% range, is reduced by the accumulation of dust, grime, pollen, and other particulates on the solar panels, collectively referred to as soiling. "A dirty solar panel can reduce its power capabilities by up to 30% in high dust/pollen or desert areas", says Seamus Curran, associate professor of physics at the University of Houston and director of the Institute for NanoEnergy, which specializes in the design, engineering, and assembly of nanostructures.^[73] The average soiling loss in the world in 2018 is estimated to be at least 3% – 4%.^[74]

Paying to have solar panels cleaned is a good investment in many regions, as of 2019.^[74] However, in some regions, cleaning is not cost-effective. In California as of 2013 soiling-induced financial losses were rarely enough to warrant the cost of washing the panels. On average, panels in California lost a little less than 0.05% of their overall efficiency per day.^[75]

There are also occupational hazards with solar panel installation and maintenance. A 2015–2018 study in the UK investigated 80 PV-related incidents of fire, with over 20 "serious fires" directly caused by PV installation, including 37 domestic buildings and 6 solar farms. In 1⁄3 of the incidents a root cause was not established and in a majority of others was caused by poor installation, faulty product or design issues. The most frequent single element causing fires was the DC isolators.^[76]

A 2021 study by kWh Analytics determined median annual degradation of PV systems at 1.09% for residential and 0.8% for non-residential ones, almost twice that previously assumed.^[77] A 2021 module reliability study found an increasing trend in solar module failure rates with 30% of manufacturers experiencing safety failures related to junction boxes (growth from 20%) and 26% bill-of-materials failures (growth from 20%).^[78]

Cleaning methods for solar panels can be divided into 5 groups: manual tools, mechanized tools (such as tractor mounted brushes), installed hydraulic systems (such as sprinklers), installed robotic systems, and deployable robots. Manual cleaning tools are by far the most prevalent method of cleaning, most likely because of the low purchase cost. However, in a Saudi Arabian study done in 2014, it was found that "installed robotic systems, mechanized systems, and installed hydraulic systems are likely the three most promising technologies for use in cleaning solar panels".^[79]

Novel self-cleaning mechanisms for solar panels are being developed. For instance, in 2019 via wet-chemically etchednanowires and a hydrophobic coating on the surface water droplets could remove 98% of dust particles, which may be especially relevant for applications in the desert.^[80][81]

In March 2022, MIT researchers announced the development of a waterless cleaning system for solar panels and mirrors to address the issue of dust accumulation, which can reduce solar output by up to 30 percent in one month. This system utilizes electrostatic repulsion to detach dust particles from the panel's surface, eliminating the need for water or brushes. An electrical charge imparted to the dust particles by passing a simple electrode over the panel causes them to be repelled by a charge applied to the panel itself. The system can be automated using a basic electric motor and guide rails.^[82]

There were 30 thousand tonnes of PV waste in 2021, and the annual amount was estimated by Bloomberg NEF to rise to more than 1 million tons by 2035 and more than 10 million by 2050.^[83] For comparison, 750 million tons of fly ash waste was produced by coal power in 2022.^[84] In the United States, around 90% of decommissioned solar panels end up in landfills as of 2023.^[85] Most parts of a solar module can be recycled including up to 95% of certain semiconductor materials or the glass as well as large amounts of ferrous and non-ferrous metals.^[86] Some private companies and non-profit organizations take-back and recycle end-of-life modules.^[87] EU law requires manufacturers to ensure their solar panels are recycled properly. Similar legislation is underway in Japan, India, and Australia.^[88] A 2023 Australian report said that there is a market for quality used panels and made recommendations for increasing reuse,^{[89]: 33â€ÅÂ}  but rules have not been implemented.^[90]

Recycling possibilities depend on the kind of technology used in the modules:

• Silicon based modules: aluminum frames and junction boxes are dismantled manually at the beginning of the process. The module is then crushed in a mill and the different fractions are separated – glass, plastics and metals.^[91] It is possible to recover more than 80% of the incoming weight.^[92] This process can be performed by flat glass recyclers, since the shape and composition of a PV module is similar to flat glass used in the building and automotive industry. The recovered glass, for example, is readily accepted by the glass foam and glass insulation industry.
• Non-silicon based modules: they require specific recycling technologies such as the use of chemical baths in order to separate the different semiconductor materials.^[93] For cadmium telluride modules, the recycling process begins by crushing the module and subsequently separating the different fractions. This recycling process is designed to recover up to 90% of the glass and 95% of the semiconductor materials contained.^[94] Some commercial-scale recycling facilities have been created in recent years by private companies.^[95]

Since 2010, there is an annual European conference bringing together manufacturers, recyclers and researchers to look at the future of PV module recycling.^[96][97]

Top producers of PV systems, by shipped capacity in gigawatts

Module producer	Shipments in 2019 (GW)[98]
Jinko Solar	14.2
JA Solar	10.3
Trina Solar	9.7
LONGi Solar	9.0
Canadian Solar	8.5
Hanwha Q Cells	7.3
Risen Energy	7.0
First Solar	5.5
GCL System	4.8
Shunfeng Photovoltaic	4.0

The production of PV systems has followed a classic learning curve effect, with significant cost reduction occurring alongside large rises in efficiency and production output.^[99]

With over 100% year-on-year growth in PV system installation, PV module makers dramatically increased their shipments of solar modules in 2019. They actively expanded their capacity and turned themselves into gigawatt GW players.^[100] According to Pulse Solar, five of the top ten PV module companies in 2019 have experienced a rise in solar panel production by at least 25% compared to 2019.^[101]

The basis of producing most solar panels is mostly on the use of silicon cells. These silicon cells are typically 10–20% efficient^[102] at converting sunlight into electricity, with newer production models exceeding 22%.^[103]

In 2018, the world's top five solar module producers in terms of shipped capacity during the calendar year of 2018 were Jinko Solar, JA Solar, Trina Solar, Longi solar, and Canadian Solar.^[104]

The price of solar electrical power has continued to fall so that in many countries it has become cheaper than fossil fuel electricity from the electricity grid since 2012, a phenomenon known as grid parity.^[107] With the rise of global awareness, institutions such as the IRS have adopted a tax credit format, refunding a portion of any solar panel array for private use.^[108] The price of a solar array only continues to fall.

Average pricing information divides in three pricing categories: those buying small quantities (modules of all sizes in the kilowatt range annually), mid-range buyers (typically up to 10 MWp annually), and large quantity buyers (self-explanatory—and with access to the lowest prices). Over the long term there is clearly a systematic reduction in the price of cells and modules. For example, in 2012 it was estimated that the quantity cost per watt was about US$0.60, which was 250 times lower than the cost in 1970 of US$150.^[109][110] A 2015 study shows price/kWh dropping by 10% per year since 1980, and predicts that solar could contribute 20% of total electricity consumption by 2030, whereas the International Energy Agency predicts 16% by 2050.^[111]

Real-world energy production costs depend a great deal on local weather conditions. In a cloudy country such as the United Kingdom, the cost per produced kWh is higher than in sunnier countries like Spain.

Following to RMI, Balance-of-System (BoS) elements, this is, non-module cost of non-microinverter solar modules (as wiring, converters, racking systems and various components) make up about half of the total costs of installations.

For merchant solar power stations, where the electricity is being sold into the electricity transmission network, the cost of solar energy will need to match the wholesale electricity price. This point is sometimes called 'wholesale grid parity' or 'busbar parity'.^[107]

Standards generally used in photovoltaic modules:

• IEC 61215 (crystalline silicon performance), 61646 (thin film performance) and 61730 (all modules, safety), 61853 (Photovoltaic module performance testing & energy rating)
• ISO 9488 Solar energy—Vocabulary.
• UL 1703 from Underwriters Laboratories
• UL 1741 from Underwriters Laboratories
• UL 2703 from Underwriters Laboratories
• CE mark
• Electrical Safety Tester (EST) Series (EST-460, EST-22V, EST-22H, EST-110).

There are many practical applications for the use of solar panels or photovoltaics. It can first be used in agriculture as a power source for irrigation. In health care solar panels can be used to refrigerate medical supplies. It can also be used for infrastructure. PV modules are used in photovoltaic systems and include a large variety of electric devices:

• Agrivoltaics
• Solar canals
• Photovoltaic power stations
• Rooftop solar PV systems
• Standalone PV systems
• Solar hybrid power systems
• Concentrated photovoltaics
• Floating solar; water-borne solar panels
• Solar planes
• Solar-powered water purification
• Solar-pumped lasers
• Solar vehicles
• Solar water heating
• Solar panels on spacecraft and space stations
• Solar landfill

With the increasing levels of rooftop photovoltaic systems, the energy flow becomes 2-way. When there is more local generation than consumption, electricity is exported to the grid. However, an electricity network traditionally is not designed to deal with the 2- way energy transfer. Therefore, some technical issues may occur. For example, in Queensland Australia, more than 30% of households used rooftop PV by the end of 2017. The duck curve appeared often for a lot of communities from 2015 onwards. An over-voltage issue may result as the electricity flows from PV households back to the network.^[113] There are solutions to manage the over voltage issue, such as regulating PV inverter power factor, new voltage and energy control equipment at the electricity distributor level, re-conducting the electricity wires, demand side management, etc. There are often limitations and costs related to these solutions.

For rooftop solar to be able to provide enough backup power during a power cut a battery is often also required.^[114]

Solar module quality assurance involves testing and evaluating solar cells and Solar Panels to ensure the quality requirements of them are met. Solar modules (or panels) are expected to have a long service life between 20 and 40 years.^[115] They should continually and reliably convey and deliver the power anticipated. Solar modules can be tested through a combination of physical tests, laboratory studies, and numerical analyses.^[116] Furthermore, solar modules need to be assessed throughout the different stages of their life cycle. Various companies such as Southern Research Energy & Environment, SGS Consumer Testing Services, TÜV Rheinland, Sinovoltaics, Clean Energy Associates (CEA), CSA Solar International and Enertis provide services in solar module quality assurance."The implementation of consistent traceable and stable manufacturing processes becomes mandatory to safeguard and ensure the quality of the PV Modules" ^[117]

This section does not cite any sources. Please help improve this section by adding citations to reliable sources. Unsourced material may be challenged and removed. (March 2022) (Learn how and when to remove this message)

The lifecycle stages of testing solar modules can include: the conceptual phase, manufacturing phase, transportation and installation, commissioning phase, and the in-service phase. Depending on the test phase, different test principles may apply.

The first stage can involve design verification where the expected output of the module is tested through computer simulation. Further, the modules ability to withstand natural environment conditions such as temperature, rain, hail, snow, corrosion, dust, lightning, horizon and near-shadow effects is tested. The layout for design and construction of the module and the quality of components and installation can also be tested at this stage.

Inspecting manufacturers of components is carried through visitation. The inspection can include assembly checks, material testing supervision and Non Destructive Testing (NDT). Certification is carried out according to ANSI/UL1703, IEC 17025, IEC 61215, IEC 61646, IEC 61701 and IEC 61730-1/-2.

• Daisy chain (electrical engineering)
• Digital modeling and fabrication
• Domestic energy consumption
• Grid-tied electrical system
• Growth of photovoltaics
• Solar charger
• Solar cooker
• Solar still



This section does not cite any sources. Please help improve this section by adding citations to reliable sources. Unsourced material may be challenged and removed. (December 2022) (Learn how and when to remove this message)

The term "unglazed air collector" refers to a solar air heating system that consists of a metal absorber without any glass or glazing over top. The most common type of unglazed collector on the market is the transpired solar collector. The technology has been extensively monitored by these government agencies, and Natural Resources Canada developed the feasibility tool RETScreen™ to model the energy savings from transpired solar collectors. Since that time, several thousand transpired solar collector systems have been installed in a variety of commercial, industrial, institutional, agricultural, and process applications in countries around the world. This technology was originally used primarily in industrial applications such as manufacturing and assembly plants where there were high ventilation requirements, stratified ceiling heat, and often negative pressure in the building. With the increasing drive to install renewable energy systems on buildings, transpired solar collectors are now used across the entire building stock because of high energy production (up to 750 peak thermal Watts/square metre), high solar conversion (up to 90%) and lower capital costs when compared against solar photovoltaic and solar water heating.

Solar air heating is a renewable energy heating technology used to heat or condition air for buildings or process heat applications. It is typically the most cost-effective of all the solar technologies, especially in large scale applications, and it addresses the largest usage of building energy in heating climates, which is space heating and industrial process heating. They are either glazed or unglazed.

Unglazed air collectors heat ambient (outside) air instead of recirculated building air. Transpired solar collectors are usually wall-mounted to capture the lower sun angle in the winter heating months as well as sun reflection off the snow and achieve their optimum performance and return on investment when operating at flow rates of between 4 and 8 CFM per square foot (72 to 144 m3/h.m2) of collector area.

The exterior surface of a transpired solar collector consists of thousands of tiny micro-perforations that allow the boundary layer of heat to be captured and uniformly drawn into an air cavity behind the exterior panels. This heated ventilation air is drawn under negative pressure into the building's ventilation system where it is then distributed via conventional means or using a solar ducting system.

Hot air that may enter an HVAC system connected to a transpired collector that has air outlets positioned along the top of the collector, particularly if the collector is west facing. To counter this problem, Matrix Energy has patented a transpired collector with a lower air outlet position and perforated cavity framing to perpetrate increased air turbulence behind the perforated absorber for increased performance.

This cutaway view shows the SolarWall transpired solar collector components and air flow. The lower air inlet mitigates the intake of heated air to the HVAC system during summer operation.

The extensive monitoring by Natural Resources Canada and NREL has shown that transpired solar collector systems reduce between 10 and 50% of the conventional heating load and that RETScreen is an accurate predictor of system performance. Transpired solar collectors act as a rainscreen and they also capture heat loss escaping from the building envelope which is collected in the collector air cavity and drawn back into the ventilation system. There is no maintenance required with solar air heating systems and the expected lifespan is over 30 years.

Unglazed transpired collectors can also be roof-mounted for applications in which there is no suitable south-facing wall or for other architectural considerations.

Each ten-foot (3.05 m) module will deliver 250 CFM (425 m3/h)of preheated fresh air typically providing annual energy savings of 1100 kWh (4 GJ) annually. This unique two-stage, modular roof-mounted transpired collector operating a nearly 90% efficiency each module delivering over 118 L/s of preheated air per two square meter collector. Up to seven collectors may be connected in series in one row, with no limit to the number of rows connected in parallel along one central duct typically yielding 4 CFM of preheated air per square foot of available roof area.

Transpired collectors can be configured to heat the air twice to increase the delivered air temperature making it suitable for space heating applications as well as ventilation air heating. In a 2-stage system, the first stage is the typical unglazed transpired collector and the second stage has glazing covering the transpired collector. The glazing allows all of that heated air from the first stage to be directed through a second set of transpired collectors for a second stage of solar heating.

Parabolic troughs, dishes and towers described in this section are used almost exclusively in solar power generating stations or for research purposes. Parabolic troughs have been used for some commercial solar air conditioning systems. Although simple, these solar concentrators are quite far from the theoretical maximum concentration.^[25][26] For example, the parabolic trough concentration is about 1/3 of the theoretical maximum for the same acceptance angle, that is, for the same overall tolerances for the system. Approaching the theoretical maximum may be achieved by using more elaborate concentrators based on nonimaging optics.^[25] Solar thermal collectors may also be used in conjunction with photovoltaic collectors to obtain combined heat and power.^[27][28]

This type of collector is generally used in solar power plants. A trough-shaped parabolic reflector is used to concentrate sunlight on an insulated tube (Dewar tube) or heat pipe, placed at the focal point, containing coolant which transfers heat from the collectors to the boilers in the power station.

With a parabolic dish collector, one or more parabolic dishes concentrate solar energy at a single focal point, similar to the way a reflecting telescope focuses starlight, or a dish antenna focuses radio waves. This geometry may be used in solar furnaces and solar power plants.

The shape of a parabola means that incoming light rays which are parallel to the dish's axis will be reflected toward the focus, no matter where on the dish they arrive. Light from the sun arrives at the Earth's surface almost completely parallel, and the dish is aligned with its axis pointing at the sun, allowing almost all incoming radiation to be reflected towards the focal point of the dish. Most losses in such collectors are due to imperfections in the parabolic shape and imperfect reflection.

Losses due to atmospheric scattering are generally minimal. However, on a hazy or foggy day, light is diffused in all directions through the atmosphere, which significantly reduces the efficiency of a parabolic dish. In dish stirling power plant designs, a stirling engine coupled to a dynamo is placed at the focus of the dish. This absorbs the energy focused onto it and converts it into electricity.

A power tower is a large tower surrounded by tracking mirrors called heliostats. These mirrors align themselves and focus sunlight on the receiver at the top of the tower, collected heat is transferred to a power station below. This design reaches very high temperatures. High temperatures are suitable for electricity generation using conventional methods like steam turbine or a direct high-temperature chemical reaction such as liquid salt.^[29] By concentrating sunlight, current systems can get better efficiency than simple solar cells. A larger area can be covered by using relatively inexpensive mirrors rather than using expensive solar cells. Concentrated light can be redirected to a suitable location via optical fiber cable for such uses as illuminating buildings. Heat storage for power production during cloudy and overnight conditions can be accomplished, often by underground tank storage of heated fluids. Molten salts have been used to good effect. Other working fluids, such as liquid metals, have also been proposed due to their superior thermal properties.^[30]

However, concentrating systems require sun tracking to maintain sunlight focus at the collector. They are unable to provide significant power in diffused light conditions. Solar cells are able to provide some output even if the sky becomes cloudy, but power output from concentrating systems drops drastically in cloudy conditions as diffused light cannot be concentrated well.

A solar thermal collector functions as a heat exchanger that converts solar radiation into thermal energy.^[31] It differs from a conventional heat exchanger in several aspects. The solar energy flux (irradiance) incident on the Earth's surface has a variable and relatively low surface density, usually not exceeding 1100 W/m² without concentration systems. Moreover, the wavelength of incident solar radiation falls between 0.3 and 3 μm, which is significantly shorter than the wavelength of radiation emitted by most radiative surfaces.^[31]

The collector absorbs the incoming solar radiation, converting it into thermal energy. This thermal energy is then transferred to a heat transfer fluid circulating within the collector.^[32] The heat transfer fluid can be air, water, oil, or a mixture including glycol (an antifreeze fluid), especially in forced circulation systems.^[32] Concentration systems may utilize phase change materials such as molten salts.^[33] The thermal energy of the heat transfer fluid can then be used directly or stored for later use.^[34] The transfer of thermal energy occurs through convection, which can be either natural or forced depending on the specific system.^[35][36]

• ISO test methods for solar collectors.^[37]
• EN 12975: Thermal solar systems and components. Solar collectors.
• EN 12976: Thermal solar systems and components. Factory-made systems.
• EN 12977: Thermal solar systems and components. Custom-made systems.
• Solar Keymark:^[38] Thermal solar systems and components. Higher level EN 1297X series certification which includes factory visits.
• International Code Council / Solar Rating & Certification Corporation:^[39] Testing is performed by independent laboratories and typically includes selection of a collector to be tested from a sample group of at least six solar collectors.
• ICC 901/ICC-SRCC™ 100: Solar Thermal Collector Standard
• ICC 900/ICC-SRCC™ 300: Solar Thermal System Standard
• ICC 902/APSP 902/ICC-SRCC™ 400: Solar Pool and Spa Heating System Standard

• Canadian government ratings of solar collectors
• Crosbyton Inventory of Records
• Feasibility of photovoltaic Cells on a Fixed Mirror Distributed Focus Solar Bowl



Multiple solar cells in an integrated group, all oriented in one plane, constitute a solar photovoltaic panel or module. Photovoltaic modules often have a sheet of glass on the sun-facing side, allowing light to pass while protecting the semiconductor wafers. Solar cells connected in series creates an additive higher voltage, while connecting in parallel yields an additive higher current.

Parallel cells without bypass or shunt diodes that experience shade can shut down the weaker (less illuminated) parallel string (each string a number of series connected cells) causing substantial power loss and possible damage because of the reverse bias applied to the shaded cells by their illuminated partners.^[9]

Solar modules can be interconnected to create an array with a desired peak DC voltage and loading current capacity. This functionality can also be accomplished with various other solar devices that do more than just create the desired voltages and currents, such as with MPPTs (maximum power point trackers) or module level power electronic (MLPE) units: microinverters or DC-DC optimizers.

Multiple solar cells assembled together in a single plane form a solar photovoltaic (PV) panel or module. These modules typically feature a glass sheet on the sun-facing side, which allows sunlight to pass through while safeguarding the semiconductor wafers from environmental factors. Connecting solar cells in series increases the voltage output, whereas parallel connections enhance the current output.^[10]

To mitigate these issues, solar modules are often equipped with bypass diodes that isolate shaded cells, preventing them from affecting the performance of the entire string. These diodes allow the current to bypass the shaded or underperforming cells, thereby minimizing power loss and reducing the risk of damage.^[11]

Typical PV system prices in 2013 in selected countries (US$/W)

	Australia	China	France	Germany	Italy	Japan	United Kingdom	United States
Residential	1.8	1.5	4.1	2.4	2.8	4.2	2.8	4.9
Commercial	1.7	1.4	2.7	1.8	1.9	3.6	2.4	4.5
Utility-scale	2.0	1.4	2.2	1.4	1.5	2.9	1.9	3.3
Source: IEA – Technology Roadmap: Solar Photovoltaic Energy report, 2014 edition[12]: 15  Note: DOE – Photovoltaic System Pricing Trends reports lower prices for the U.S.[13]

By 2020, the United States cost per watt for a utility scale system had declined to $0.94.^[14]

Solar cells were first used in a prominent application when they were proposed and flown on the Vanguard satellite in 1958, as an alternative power source to the primary battery power source. By adding cells to the outside of the body, the mission time could be extended with no major changes to the spacecraft or its power systems. In 1959 the United States launched Explorer 6, featuring large wing-shaped solar arrays, which became a common feature in satellites. These arrays consisted of 9600 Hoffman solar cells.

By the 1960s, solar cells were (and still are) the main power source for most Earth orbiting satellites and a number of probes into the Solar System, since they offered the best power-to-weight ratio. The success of the space solar power market drove the development of higher efficiencies in solar cells, due to limited other power options and the desire for the best possible cells, up until the National Science Foundation "Research Applied to National Needs" program began to push development of solar cells for terrestrial applications.

In the early 1990s the technology used for space solar cells diverged from the silicon technology used by terrestrial panels, with the spacecraft application shifting to gallium arsenide-based III-V semiconductor materials, which then evolved into the modern III-V multijunction photovoltaic cell used on spacecraft that are lightweight, compact, flexible, and highly efficient. State of the art technology implemented on satellites uses multi-junction photovoltaic cells, which are composed of different p–n junctions with varying bandgaps in order to utilize a wider spectrum of the Sun's energy. Space solar cells additionally diverged from the protective layer used by terrestrial panels, with space applications using flexible laminate layers.

Additionally, large satellites require the use of large solar arrays to produce electricity. These solar arrays need to be broken down to fit in the geometric constraints of the launch vehicle the satellite travels on before being injected into orbit. Historically, solar cells on satellites consisted of several small terrestrial panels folded together. These small panels would be unfolded into a large panel after the satellite is deployed in its orbit. Newer satellites aim to use flexible rollable solar arrays that are very lightweight and can be packed into a very small volume. The smaller size and weight of these flexible arrays drastically decreases the overall cost of launching a satellite due to the direct relationship between payload weight and launch cost of a launch vehicle.^[15]

In 2020, the US Naval Research Laboratory conducted its first test of solar power generation in a satellite, the Photovoltaic Radio-frequency Antenna Module (PRAM) experiment aboard the Boeing X-37.^[16][17]

The photovoltaic effect was experimentally demonstrated first by French physicist Edmond Becquerel. In 1839, at age 19, he built the world's first photovoltaic cell in his father's laboratory. Willoughby Smith first described the "Effect of Light on Selenium during the passage of an Electric Current" in a 20 February 1873 issue of Nature. In 1883 Charles Fritts built the first solid state photovoltaic cell by coating the semiconductor selenium with a thin layer of gold to form the junctions; the device was only around 1% efficient.^[18] Other milestones include:

• 1888 – Russian physicist Aleksandr Stoletov built the first cell based on the outer photoelectric effect discovered by Heinrich Hertz in 1887.^[19]
• 1904 – Julius Elster, together with Hans Friedrich Geitel, devised the first practical photoelectric cell.^[20]
• 1905 – Albert Einstein proposed a new quantum theory of light and explained the photoelectric effect in a landmark paper, for which he received the Nobel Prize in Physics in 1921.^[21]
• 1941 – Vadim Lashkaryov discovered p–n junctions in Cu₂O and Ag₂S protocells.^[22]
• 1946 – Russell Ohl patented the modern junction semiconductor solar cell,^[23] while working on the series of advances that would lead to the transistor.
• 1948 - Introduction to the World of Semiconductors states Kurt Lehovec may have been the first to explain the photo-voltaic effect in the peer-reviewed journal Physical Review.^[24][25]
• 1954 – The first practical photovoltaic cell was publicly demonstrated at Bell Laboratories.^[26] The inventors were Calvin Souther Fuller, Daryl Chapin and Gerald Pearson.^[27]
• 1958 – Solar cells gained prominence with their incorporation onto the Vanguard I satellite.^[28]

Pricing and efficiency Improvements were gradual over the 1960s. One reason that costs remained high was because space users were willing to pay for the best possible cells, leaving no reason to invest in lower-cost, less-efficient solutions. Also, price was determined largely by the semiconductor industry; their move to integrated circuits in the 1960s led to the availability of larger boules at lower relative prices. As their price fell, the price of the resulting cells did as well. These effects lowered 1971 cell costs to some $100,000 per watt.^[29]

In late 1969 Elliot Berman joined Exxon's task force which was looking for projects 30 years in the future and in April 1973 he founded Solar Power Corporation (SPC), a wholly owned subsidiary of Exxon at that time.^[30][31][32] The group concluded that electrical power would be much more expensive by 2000, and felt that the increase in price would make alternative energy sources more attractive. He conducted a market study and concluded that a price per watt of about $20/watt would create significant demand.^[30] To reduce costs, the team

• eliminated the steps of polishing the wafers and coating them with an anti-reflective layer, by relying on rough-sawn wafer surfaces.
• replaced the expensive materials and hand wiring used in space applications with a printed circuit board on the back, acrylic plastic on the front, and silicone glue between the two, "potting" the cells.^[33]
• used solar cells that could be made using cast-off material from the electronics market.

By 1973 they announced a product, and SPC convinced Tideland Signal to use its panels to power navigational buoys, initially for the U.S. Coast Guard.^[31]

Research into solar power for terrestrial applications became prominent with the U.S. National Science Foundation's Advanced Solar Energy Research and Development Division within the "Research Applied to National Needs" program, which ran from 1969 to 1977,^[34] and funded research on developing solar power for ground electrical power systems. A 1973 conference, the "Cherry Hill Conference", set forth the technology goals required to achieve this goal and outlined an ambitious project for achieving them, kicking off an applied research program that would be ongoing for several decades.^[35] The program was eventually taken over by the Energy Research and Development Administration (ERDA),^[36] which was later merged into the U.S. Department of Energy.

Following the 1973 oil crisis, oil companies used their higher profits to start (or buy) solar firms, and were for decades the largest producers. Exxon, ARCO, Shell, Amoco (later purchased by BP) and Mobil all had major solar divisions during the 1970s and 1980s. Technology companies also participated, including General Electric, Motorola, IBM, Tyco and RCA.^[37]

Adjusting for inflation, it cost $96 per watt for a solar module in the mid-1970s. Process improvements and a very large boost in production have brought that figure down more than 99%, to 30¢ per watt in 2018 ^[40] and as low as 20¢ per watt in 2020. ^[41] Swanson's law is an observation similar to Moore's Law that states that solar cell prices fall 20% for every doubling of industry capacity. It was featured in an article in the British weekly newspaper The Economist in late 2012.^[42] Balance of system costs are now higher than the solar panels alone, where in 2018 commercial arrays could be built at below $1.00 a watt, fully commissioned.^[14]

Over decades, costs for solar cells and panels has declined for many reasons:

1. Larger boules. When the semiconductor industry moved to ever-larger boules, older equipment became inexpensive.
2. Larger physical solar cell size. Sizes grew as surplus semiconductor equipment became available. ARCO Solar's original panels used cells 2 to 4 inches (50 to 100 mm) in diameter. Panels in the 1990s and early 2000s generally used 125 mm wafers; since 2008, almost all new panels use greater than 156mm cells,^[43] and by 2020 even larger 182mm ‘M10’ cells.^[44]
3. Availability of large, high-quality glass sheets to cover the panels. Widespread introduction of flat screen televisions in the late 1990s and early 2000s led to such availability.
4. Thinner solar cells. High silicon prices in 2004–2008 encouraged silicon solar cell manufacturers to reduce silicon consumption by making them thinner; whereby 2008, according to Jef Poortmans, director of IMEC's organic and solar department, cells used 8–9 grams (0.28–0.32 oz) of silicon per watt of power generation, with typical wafer thicknesses in the neighborhood of 200 microns.

During the 1990s, polysilicon ("poly") cells became increasingly popular. These cells offer less efficiency than their monosilicon ("mono") counterparts, but are grown in large vats that reduce cost. By the mid-2000s, poly was dominant in the low-cost panel market, but more recently the monosilicon cells have returned to widespread use due to the efficiency gains.

Crystalline silicon panels dominate worldwide markets and are mostly manufactured in China and Taiwan. By late 2011, a drop in European demand dropped prices for crystalline solar modules to about $1.09^[45] per watt down sharply from 2010. Prices continued to fall in 2012, reaching $0.62/watt by 4Q2012.^[46]

It was anticipated that electricity from PV will be competitive with wholesale electricity costs all across Europe and the energy payback time of crystalline silicon modules can be reduced to below 0.5 years by 2020.^[47]

Falling costs are considered one of the biggest factors in the rapid growth of renewable energy, of 2016, solar PV is growing fastest in Asia, with China and Japan currently accounting for half of worldwide deployment.^[48] Costs of solar photovoltaic electricity fell by ~85% between 2010 (when solar and wind made up 1.7% of global electricity generation) and 2021 (where they made up 8.7%).^[49] Global installed PV capacity reached at least 301 gigawatts in 2016, and grew to supply 1.3% of global power by 2016.^[50] In 2019 solar cells accounted for ~3 % of the world's electricity generation at 720 Tw-hr.^[51]

Solar-specific feed-in tariffs vary by and within country countries. Such tariffs can encourage the development of solar power projects and to achieve grid parity. Grid parity, the point at which photovoltaic electricity is equal to or cheaper than grid power without subsidies, is expected to be first achieved in areas with abundant sun and high electricity costs such as in California and Japan.^[52] In 2007 BP claimed grid parity for Hawaii and other islands that otherwise use diesel fuel to produce electricity. George W. Bush set 2015 as the date for grid parity in the US.^[53][54] The Photovoltaic Association reported in 2012 that Australia had reached grid parity (ignoring feed in tariffs).^[55]

The price of solar panels fell steadily for 40 years, interrupted in 2004 when high subsidies in Germany drastically increased demand there and greatly increased the price of purified silicon (which is used in computer chips as well as solar panels). The Great Recession and the onset of Chinese manufacturing caused prices to resume their decline. In the four years after January 2008 prices for solar modules in Germany dropped from €3 to €1 per peak watt. During that same time production capacity surged with an annual growth of more than 50%. China increased solar panel production market share from 8% in 2008 to over 55% in the last quarter of 2010.^[56] In December 2012 the price of Chinese solar panels had dropped to $0.60/Wp (crystalline modules).^[57] (The abbreviation Wp stands for watt peak capacity, or the maximum capacity under optimal conditions.^[58])

As of the end of 2016, it was reported that spot prices for assembled solar panels (not cells) had fallen to a record-low of US$0.36/Wp. The second largest supplier, Canadian Solar Inc., had reported costs of US$0.37/Wp in the third quarter of 2016, having dropped $0.02 from the previous quarter, and hence was probably still at least breaking even. Many producers expected costs would drop to the vicinity of $0.30 by the end of 2017.^[59] It was also reported that new solar installations were cheaper than coal-based thermal power plants in some regions of the world, and this was expected to be the case in most of the world within a decade.^[60]

A solar cell is made of semiconducting materials, such as silicon, that have been fabricated into a p–n junction. Such junctions are made by doping one side of the device p-type and the other n-type, for example in the case of silicon by introducing small concentrations of boron or phosphorus respectively.

In operation, photons in sunlight hit the solar cell and are absorbed by the semiconductor. When the photons are absorbed, electrons are excited from the valence band to the conduction band (or from occupied to unoccupied molecular orbitals in the case of an organic solar cell), producing electron-hole pairs. If the electron-hole pairs are created near the junction between p-type and n-type materials the local electric field sweeps them apart to opposite electrodes, producing an excess of electrons on one side and an excess of holes on the other. When the solar cell is unconnected (or the external electrical load is very high) the electrons and holes will ultimately restore equilibrium by diffusing back across the junction against the field and recombine with each other giving off heat, but if the load is small enough then it is easier for equilibrium to be restored by the excess electrons going around the external circuit, doing useful work along the way.

The most commonly known solar cell is configured as a large-area p–n junction made from silicon. Other possible solar cell types are organic solar cells, dye sensitized solar cells, perovskite solar cells, quantum dot solar cells, etc. The illuminated side of a solar cell generally has a transparent conducting film for allowing light to enter into the active material and to collect the generated charge carriers. Typically, films with high transmittance and high electrical conductance such as indium tin oxide, conducting polymers, or conducting nanowire networks are used for the purpose.^[61]

Solar cell efficiency may be broken down into reflectance efficiency, thermodynamic efficiency, charge carrier separation efficiency and conductive efficiency. The overall efficiency is the product of these individual metrics.

The power conversion efficiency of a solar cell is a parameter which is defined by the fraction of incident power converted into electricity.^[62]

A solar cell has a voltage dependent efficiency curve, temperature coefficients, and allowable shadow angles.

Due to the difficulty in measuring these parameters directly, other parameters are substituted: thermodynamic efficiency, quantum efficiency, integrated quantum efficiency, V_OC ratio, and fill factor. Reflectance losses are a portion of quantum efficiency under "external quantum efficiency". Recombination losses make up another portion of quantum efficiency, V_OC ratio, and fill factor. Resistive losses are predominantly categorized under fill factor, but also make up minor portions of quantum efficiency, V_OC ratio.

The fill factor is the ratio of the actual maximum obtainable power to the product of the open-circuit voltage and short-circuit current. This is a key parameter in evaluating performance. In 2009, typical commercial solar cells had a fill factor > 0.70. Grade B cells were usually between 0.4 and 0.7.^[63] Cells with a high fill factor have a low equivalent series resistance and a high equivalent shunt resistance, so less of the current produced by the cell is dissipated in internal losses.

Single p–n junction crystalline silicon devices are now approaching the theoretical limiting power efficiency of 33.16%,^[64] noted as the Shockley–Queisser limit in 1961. In the extreme, with an infinite number of layers, the corresponding limit is 86% using concentrated sunlight.^[65]

In 2014, three companies broke the record of 25.6% for a silicon solar cell. Panasonic's was the most efficient. The company moved the front contacts to the rear of the panel, eliminating shaded areas. In addition they applied thin silicon films to the (high quality silicon) wafer's front and back to eliminate defects at or near the wafer surface.^[66]

In 2015, a 4-junction GaInP/GaAs//GaInAsP/GaInAs solar cell achieved a new laboratory record efficiency of 46.1% (concentration ratio of sunlight = 312) in a French-German collaboration between the Fraunhofer Institute for Solar Energy Systems (Fraunhofer ISE), CEA-LETI and SOITEC.^[67]

In September 2015, Fraunhofer ISE announced the achievement of an efficiency above 20% for epitaxial wafer cells. The work on optimizing the atmospheric-pressure chemical vapor deposition (APCVD) in-line production chain was done in collaboration with NexWafe GmbH, a company spun off from Fraunhofer ISE to commercialize production.^[68][69]

For triple-junction thin-film solar cells, the world record is 13.6%, set in June 2015.^[70]

In 2016, researchers at Fraunhofer ISE announced a GaInP/GaAs/Si triple-junction solar cell with two terminals reaching 30.2% efficiency without concentration.^[71]

In 2017, a team of researchers at National Renewable Energy Laboratory (NREL), EPFL and CSEM (Switzerland) reported record one-sun efficiencies of 32.8% for dual-junction GaInP/GaAs solar cell devices. In addition, the dual-junction device was mechanically stacked with a Si solar cell, to achieve a record one-sun efficiency of 35.9% for triple-junction solar cells.^[72]

Solar cells are typically named after the semiconducting material of which they are composed. These materials have varying characteristics to absorb optimal available sunlight spectrum. Some cells are designed to handle sunlight that reaches the Earth's surface, while others are optimized for use in space. Solar cells can be made of a single layer of light-absorbing material (single-junction) or use multiple physical configurations (multi-junctions) to take advantage of various absorption and charge separation mechanisms.

Solar cells can be classified into first, second and third generation:

1. First generation cells—also called conventional, traditional or wafer-based cells—are made of crystalline silicon, the commercially predominant PV technology, that includes materials such as polysilicon and monocrystalline silicon.
2. Second generation cells are thin film solar cells, that include amorphous silicon, CdTe and CIGS cells and are commercially significant in utility-scale photovoltaic power stations, building integrated photovoltaics or in small stand-alone power system.
3. Third generation of solar cells includes a number of thin-film technologies often described as emerging photovoltaics—most of them have not yet been commercially applied and are still in the research or development phase. Many use organic materials, often organometallic compounds as well as inorganic substances. Despite the fact that their efficiencies had been low and the stability of the absorber material was often too short for commercial applications, there is research into these technologies as they promise to achieve the goal of producing low-cost, high-efficiency solar cells.^[74]

As of 2016, the most popular and efficient solar cells were those made from thin wafers of silicon which are also the oldest solar cell technology.^[75]

By far, the most prevalent bulk material for solar cells is crystalline silicon (c-Si), also known as "solar grade silicon".^[76] Bulk silicon is separated into multiple categories according to crystallinity and crystal size in the resulting ingot, ribbon or wafer. These cells are entirely based around the concept of a p–n junction. Solar cells made of c-Si are made from wafers between 160 and 240 micrometers thick.

Monocrystalline silicon (mono-Si) solar cells feature a single-crystal composition that enables electrons to move more freely than in a multi-crystal configuration. Consequently, monocrystalline solar panels deliver a higher efficiency than their multicrystalline counterparts.^[77] The corners of the cells look clipped, like an octagon, because the wafer material is cut from cylindrical ingots, that are typically grown by the Czochralski process. Solar panels using mono-Si cells display a distinctive pattern of small white diamonds.

Epitaxial wafers of crystalline silicon can be grown on a monocrystalline silicon "seed" wafer by chemical vapor deposition (CVD), and then detached as self-supporting wafers of some standard thickness (e.g., 250 μm) that can be manipulated by hand, and directly substituted for wafer cells cut from monocrystalline silicon ingots. Solar cells made with this "kerfless" technique can have efficiencies approaching those of wafer-cut cells, but at appreciably lower cost if the CVD can be done at atmospheric pressure in a high-throughput inline process.^[68][69] The surface of epitaxial wafers may be textured to enhance light absorption.^[78][79]

In June 2015, it was reported that heterojunction solar cells grown epitaxially on n-type monocrystalline silicon wafers had reached an efficiency of 22.5% over a total cell area of 243.4 cm$\displaystyle ^2$.^[80]

Polycrystalline silicon, or multicrystalline silicon (multi-Si) cells are made from cast square ingots—large blocks of molten silicon carefully cooled and solidified. They consist of small crystals giving the material its typical metal flake effect. Polysilicon cells are the most common type used in photovoltaics and are less expensive, but also less efficient, than those made from monocrystalline silicon.

Ribbon silicon is a type of polycrystalline silicon—it is formed by drawing flat thin films from molten silicon and results in a polycrystalline structure. These cells are cheaper to make than multi-Si, due to a great reduction in silicon waste, as this approach does not require sawing from ingots.^[81] However, they are also less efficient.

This form was developed in the 2000s and introduced commercially around 2009. Also called cast-mono, this design uses polycrystalline casting chambers with small "seeds" of mono material. The result is a bulk mono-like material that is polycrystalline around the outsides. When sliced for processing, the inner sections are high-efficiency mono-like cells (but square instead of "clipped"), while the outer edges are sold as conventional poly. This production method results in mono-like cells at poly-like prices.^[82]

Thin-film technologies reduce the amount of active material in a cell. Most designs sandwich active material between two panes of glass. Since silicon solar panels only use one pane of glass, thin film panels are approximately twice as heavy as crystalline silicon panels, although they have a smaller ecological impact (determined from life cycle analysis).^{[83] [84]}

Cadmium telluride is the only thin film material so far to rival crystalline silicon in cost/watt. However cadmium is highly toxic and tellurium (anion: "telluride") supplies are limited. The cadmium present in the cells would be toxic if released. However, release is impossible during normal operation of the cells and is unlikely during fires in residential roofs.^[85] A square meter of CdTe contains approximately the same amount of Cd as a single C cell nickel-cadmium battery, in a more stable and less soluble form.^[85]

Copper indium gallium selenide (CIGS) is a direct band gap material. It has the highest efficiency (~20%) among all commercially significant thin film materials (see CIGS solar cell). Traditional methods of fabrication involve vacuum processes including co-evaporation and sputtering. Recent developments at IBM and Nanosolar attempt to lower the cost by using non-vacuum solution processes.^[86]

Silicon thin-film cells are mainly deposited by chemical vapor deposition (typically plasma-enhanced, PE-CVD) from silane gas and hydrogen gas. Depending on the deposition parameters, this can yield amorphous silicon (a-Si or a-Si:H), protocrystalline silicon or nanocrystalline silicon (nc-Si or nc-Si:H), also called microcrystalline silicon.^[87]

Amorphous silicon is the most well-developed thin film technology to-date. An amorphous silicon (a-Si) solar cell is made of non-crystalline or microcrystalline silicon. Amorphous silicon has a higher bandgap (1.7 eV) than crystalline silicon (c-Si) (1.1 eV), which means it absorbs the visible part of the solar spectrum more strongly than the higher power density infrared portion of the spectrum. The production of a-Si thin film solar cells uses glass as a substrate and deposits a very thin layer of silicon by plasma-enhanced chemical vapor deposition (PECVD).

Protocrystalline silicon with a low volume fraction of nanocrystalline silicon is optimal for high open-circuit voltage.^[88] Nc-Si has about the same bandgap as c-Si and nc-Si and a-Si can advantageously be combined in thin layers, creating a layered cell called a tandem cell. The top cell in a-Si absorbs the visible light and leaves the infrared part of the spectrum for the bottom cell in nc-Si.

The semiconductor material gallium arsenide (GaAs) is also used for single-crystalline thin film solar cells. Although GaAs cells are very expensive^{[citation needed]}, they hold the world's record in efficiency for a single-junction solar cell at 28.8%.^[89] Typically fabricated on crystalline silicon wafer^[90] with a 41% fill factor, by moving to porous silicon fill factor can be increased to 56% with potentially reduced cost. Using less active GaAs material by fabricating nanowires is another potential pathway to cost reduction.^[91] GaAs is more commonly used in multijunction photovoltaic cells for concentrated photovoltaics (CPV, HCPV) and for solar panels on spacecraft, as the industry favours efficiency over cost for space-based solar power. Based on the previous literature and some theoretical analysis, there are several reasons why GaAs has such high power conversion efficiency for three main reasons:

1. GaAs bandgap is 1.43ev which is almost ideal for solar cells.
2. Gallium is a by-product of high temperature smelting of other metals, allowing GaAs cells to be relatively insensitive to heat and it can keep high efficiency when temperature is quite high in application.
3. Using GaAs as the active layer in a solar cell, engineers can have multiple choices of other layers which can more efficiently generate electrons and holes in GaAs.

Multi-junction cells consist of multiple thin films, each essentially a solar cell grown on top of another, typically using metalorganic vapour phase epitaxy. Each layer has a different band gap energy to allow it to absorb electromagnetic radiation over a different portion of the spectrum. Multi-junction cells were originally developed for special applications such as satellites and space exploration, but are now used increasingly in terrestrial concentrator photovoltaics (CPV), an emerging technology that uses lenses and curved mirrors to concentrate sunlight onto small, highly efficient multi-junction solar cells. By concentrating sunlight up to a thousand times, High concentration photovoltaics (HCPV) has the potential to outcompete conventional solar PV in the future.^{[92]: 21, 26â€ÅÂ}

Tandem solar cells based on monolithic, series connected, gallium indium phosphide (GaInP), gallium arsenide (GaAs), and germanium (Ge) p–n junctions, are increasing sales, despite cost pressures.^[93] Between December 2006 and December 2007, the cost of 4N gallium metal rose from about $350 per kg to $680 per kg. Additionally, germanium metal prices have risen substantially to $1000–1200 per kg this year. Those materials include gallium (4N, 6N and 7N Ga), arsenic (4N, 6N and 7N) and germanium, pyrolitic boron nitride (pBN) crucibles for growing crystals, and boron oxide, these products are critical to the entire substrate manufacturing industry.^{[citation needed]}

A triple-junction cell, for example, may consist of the semiconductors: GaAs, Ge, and GaInP
₂.^[94] Triple-junction GaAs solar cells were used as the power source of the Dutch four-time World Solar Challenge winners Nuna in 2003, 2005 and 2007 and by the Dutch solar cars Solutra (2005), Twente One (2007) and 21Revolution (2009).^{[citation needed]} GaAs based multi-junction devices are the most efficient solar cells to date. On 15 October 2012, triple junction metamorphic cells reached a record high of 44%.^[95] In 2022, researchers at Fraunhofer Institute for Solar Energy Systems ISE in Freiburg, Germany, demonstrated a record solar cell efficiency of 47.6% under 665-fold sunlight concentration with a four-junction concentrator solar cell.^[96][97]

In 2016, a new approach was described for producing hybrid photovoltaic wafers combining the high efficiency of III-V multi-junction solar cells with the economies and wealth of experience associated with silicon. The technical complications involved in growing the III-V material on silicon at the required high temperatures, a subject of study for some 30 years, are avoided by epitaxial growth of silicon on GaAs at low temperature by plasma-enhanced chemical vapor deposition (PECVD).^[98]

Si single-junction solar cells have been widely studied for decades and are reaching their practical efficiency of ~26% under 1-sun conditions.^[99] Increasing this efficiency may require adding more cells with bandgap energy larger than 1.1 eV to the Si cell, allowing to convert short-wavelength photons for generation of additional voltage. A dual-junction solar cell with a band gap of 1.6–1.8 eV as a top cell can reduce thermalization loss, produce a high external radiative efficiency and achieve theoretical efficiencies over 45%.^[100] A tandem cell can be fabricated by growing the GaInP and Si cells. Growing them separately can overcome the 4% lattice constant mismatch between Si and the most common III–V layers that prevent direct integration into one cell. The two cells therefore are separated by a transparent glass slide so the lattice mismatch does not cause strain to the system. This creates a cell with four electrical contacts and two junctions that demonstrated an efficiency of 18.1%. With a fill factor (FF) of 76.2%, the Si bottom cell reaches an efficiency of 11.7% (± 0.4) in the tandem device, resulting in a cumulative tandem cell efficiency of 29.8%.^[101] This efficiency exceeds the theoretical limit of 29.4%^[102] and the record experimental efficiency value of a Si 1-sun solar cell, and is also higher than the record-efficiency 1-sun GaAs device. However, using a GaAs substrate is expensive and not practical. Hence researchers try to make a cell with two electrical contact points and one junction, which does not need a GaAs substrate. This means there will be direct integration of GaInP and Si.

Perovskite solar cells are solar cells that include a perovskite-structured material as the active layer. Most commonly, this is a solution-processed hybrid organic-inorganic tin or lead halide based material. Efficiencies have increased from below 5% at their first usage in 2009 to 25.5% in 2020, making them a very rapidly advancing technology and a hot topic in the solar cell field.^[103] Researchers at University of Rochester reported in 2023 that significant further improvements in cell efficiency can be achieved by utilizing Purcell effect.^[104]

Perovskite solar cells are also forecast to be extremely cheap to scale up, making them a very attractive option for commercialisation. So far most types of perovskite solar cells have not reached sufficient operational stability to be commercialised, although many research groups are investigating ways to solve this.^[105] Energy and environmental sustainability of perovskite solar cells and tandem perovskite are shown to be dependent on the structures.^{[106][107][108]} Photonic front contacts for light management can improve the perovskite cells' performance, via enhanced broadband absorption, while allowing better operational stability due to protection against the harmful high-energy (above Visible) radiation.^[109] The inclusion of the toxic element lead in the most efficient perovskite solar cells is a potential problem for commercialisation.^[110]

With a transparent rear side, bifacial solar cells can absorb light from both the front and rear sides. Hence, they can produce more electricity than conventional monofacial solar cells. The first patent of bifacial solar cells was filed by Japanese researcher Hiroshi Mori, in 1966.^[111] Later, it is said that Russia was the first to deploy bifacial solar cells in their space program in the 1970s.^{[citation needed]} In 1976, the Institute for Solar Energy of the Technical University of Madrid, began a research program for the development of bifacial solar cells led by Prof. Antonio Luque. Based on 1977 US and Spanish patents by Luque, a practical bifacial cell was proposed with a front face as anode and a rear face as cathode; in previously reported proposals and attempts both faces were anodic and interconnection between cells was complicated and expensive.^{[112][113][114]} In 1980, Andrés Cuevas, a PhD student in Luque's team, demonstrated experimentally a 50% increase in output power of bifacial solar cells, relative to identically oriented and tilted monofacial ones, when a white background was provided.^[115] In 1981 the company Isofoton was founded in Málaga to produce the developed bifacial cells, thus becoming the first industrialization of this PV cell technology. With an initial production capacity of 300 kW/yr of bifacial solar cells, early landmarks of Isofoton's production were the 20kWp power plant in San Agustín de Guadalix, built in 1986 for Iberdrola, and an off grid installation by 1988 also of 20kWp in the village of Noto Gouye Diama (Senegal) funded by the Spanish international aid and cooperation programs.

Due to the reduced manufacturing cost, companies have again started to produce commercial bifacial modules since 2010. By 2017, there were at least eight certified PV manufacturers providing bifacial modules in North America. The International Technology Roadmap for Photovoltaics (ITRPV) predicted that the global market share of bifacial technology will expand from less than 5% in 2016 to 30% in 2027.^[116]

Due to the significant interest in the bifacial technology, a recent study has investigated the performance and optimization of bifacial solar modules worldwide.^[117][118] The results indicate that, across the globe, ground-mounted bifacial modules can only offer ~10% gain in annual electricity yields compared to the monofacial counterparts for a ground albedo coefficient of 25% (typical for concrete and vegetation groundcovers). However, the gain can be increased to ~30% by elevating the module 1 m above the ground and enhancing the ground albedo coefficient to 50%. Sun et al. also derived a set of empirical equations that can optimize bifacial solar modules analytically.^[117] In addition, there is evidence that bifacial panels work better than traditional panels in snowy environments as bifacials on dual-axis trackers made 14% more electricity in a year than their monofacial counterparts and 40% during the peak winter months.^[119]

An online simulation tool is available to model the performance of bifacial modules in any arbitrary location across the entire world. It can also optimize bifacial modules as a function of tilt angle, azimuth angle, and elevation above the ground.^[120]

Intermediate band photovoltaics in solar cell research provides methods for exceeding the Shockley–Queisser limit on the efficiency of a cell. It introduces an intermediate band (IB) energy level in between the valence and conduction bands. Theoretically, introducing an IB allows two photons with energy less than the bandgap to excite an electron from the valence band to the conduction band. This increases the induced photocurrent and thereby efficiency.^[121]

Luque and Marti first derived a theoretical limit for an IB device with one midgap energy level using detailed balance. They assumed no carriers were collected at the IB and that the device was under full concentration. They found the IB maximum efficiency to be 63.2%, for a bandgap of 1.95eV with the IB 0.71eV from either the valence or conduction band ans compared to the under one sun illumination limiting efficiency of 47%.^[122] Several means are under study to realize IB semiconductors with such optimum 3-bandgap configuration, namely via materials engineering (controlled inclusion of deep level impurities or highly mismatched alloys) and nano-structuring (quantum-dots in host hetero-crystals).^[123]

In 2014, researchers at California NanoSystems Institute discovered using kesterite and perovskite improved electric power conversion efficiency for solar cells.^[124]

In December 2022, it was reported that MIT researchers had developed ultralight fabric solar cells. These cells offer a weight one-hundredth that of traditional panels while generating 18 times more power per kilogram. Thinner than a human hair, these cells can be laminated onto various surfaces, such as boat sails, tents, tarps, or drone wings, to extend their functionality. Using ink-based materials and scalable techniques, researchers coat the solar cell structure with printable electronic inks, completing the module with screen-printed electrodes. Tested on high-strength fabric, the cells produce 370 watts-per-kilogram, representing an improvement over conventional solar cells.^[125]

Photon upconversion is the process of using two low-energy (e.g., infrared) photons to produce one higher energy photon; downconversion is the process of using one high energy photon (e.g., ultraviolet) to produce two lower energy photons. Either of these techniques could be used to produce higher efficiency solar cells by allowing solar photons to be more efficiently used. The difficulty, however, is that the conversion efficiency of existing phosphors exhibiting up- or down-conversion is low, and is typically narrow band.

One upconversion technique is to incorporate lanthanide-doped materials (Er³⁺
, Yb³⁺
, Ho³⁺
or a combination), taking advantage of their luminescence to convert infrared radiation to visible light. Upconversion process occurs when two infrared photons are absorbed by rare-earth ions to generate a (high-energy) absorbable photon. As example, the energy transfer upconversion process (ETU), consists in successive transfer processes between excited ions in the near infrared. The upconverter material could be placed below the solar cell to absorb the infrared light that passes through the silicon. Useful ions are most commonly found in the trivalent state. Er⁺
ions have been the most used. Er³⁺
ions absorb solar radiation around 1.54 μm. Two Er³⁺
ions that have absorbed this radiation can interact with each other through an upconversion process. The excited ion emits light above the Si bandgap that is absorbed by the solar cell and creates an additional electron–hole pair that can generate current. However, the increased efficiency was small. In addition, fluoroindate glasses have low phonon energy and have been proposed as suitable matrix doped with Ho³⁺
ions.^[126]

Dye-sensitized solar cells (DSSCs) are made of low-cost materials and do not need elaborate manufacturing equipment, so they can be made in a DIY fashion. In bulk it should be significantly less expensive than older solid-state cell designs. DSSC's can be engineered into flexible sheets and although its conversion efficiency is less than the best thin film cells, its price/performance ratio may be high enough to allow them to compete with fossil fuel electrical generation.

Typically a ruthenium metalorganic dye (Ru-centered) is used as a monolayer of light-absorbing material, which is adsorbed onto a thin film of titanium dioxide. The dye-sensitized solar cell depends on this mesoporous layer of nanoparticulate titanium dioxide (TiO₂) to greatly amplify the surface area (200–300 m²/g TiO
₂, as compared to approximately 10 m²/g of flat single crystal) which allows for a greater number of dyes per solar cell area (which in term in increases the current). The photogenerated electrons from the light absorbing dye are passed on to the n-type TiO
₂ and the holes are absorbed by an electrolyte on the other side of the dye. The circuit is completed by a redox couple in the electrolyte, which can be liquid or solid. This type of cell allows more flexible use of materials and is typically manufactured by screen printing or ultrasonic nozzles, with the potential for lower processing costs than those used for bulk solar cells. However, the dyes in these cells also suffer from degradation under heat and UV light and the cell casing is difficult to seal due to the solvents used in assembly. Due to this reason, researchers have developed solid-state dye-sensitized solar cells that use a solid electrolyte to avoid leakage.^[127] The first commercial shipment of DSSC solar modules occurred in July 2009 from G24i Innovations.^[128]

Quantum dot solar cells (QDSCs) are based on the Gratzel cell, or dye-sensitized solar cell architecture, but employ low band gap semiconductor nanoparticles, fabricated with crystallite sizes small enough to form quantum dots (such as CdS, CdSe, Sb
₂S
₃, PbS, etc.), instead of organic or organometallic dyes as light absorbers. Due to the toxicity associated with Cd and Pb based compounds there are also a series of "green" QD sensitizing materials in development (such as CuInS_2, CuInSe₂ and CuInSeS).^[129] QD's size quantization allows for the band gap to be tuned by simply changing particle size. They also have high extinction coefficients and have shown the possibility of multiple exciton generation.^[130]

In a QDSC, a mesoporous layer of titanium dioxide nanoparticles forms the backbone of the cell, much like in a DSSC. This TiO
₂ layer can then be made photoactive by coating with semiconductor quantum dots using chemical bath deposition, electrophoretic deposition or successive ionic layer adsorption and reaction. The electrical circuit is then completed through the use of a liquid or solid redox couple. The efficiency of QDSCs has increased^[131] to over 5% shown for both liquid-junction^[132] and solid state cells,^[133] with a reported peak efficiency of 11.91%.^[134] In an effort to decrease production costs, the Prashant Kamat research group^[135] demonstrated a solar paint made with TiO
₂ and CdSe that can be applied using a one-step method to any conductive surface with efficiencies over 1%.^[136] However, the absorption of quantum dots (QDs) in QDSCs is weak at room temperature.^[137] The plasmonic nanoparticles can be utilized to address the weak absorption of QDs (e.g., nanostars).^[138] Adding an external infrared pumping source to excite intraband and interband transition of QDs is another solution.^[137]

Organic solar cells and polymer solar cells are built from thin films (typically 100 nm) of organic semiconductors including polymers, such as polyphenylene vinylene and small-molecule compounds like copper phthalocyanine (a blue or green organic pigment) and carbon fullerenes and fullerene derivatives such as PCBM.

They can be processed from liquid solution, offering the possibility of a simple roll-to-roll printing process, potentially leading to inexpensive, large-scale production. In addition, these cells could be beneficial for some applications where mechanical flexibility and disposability are important. Current cell efficiencies are, however, very low, and practical devices are essentially non-existent.

Energy conversion efficiencies achieved to date using conductive polymers are very low compared to inorganic materials. However, Konarka Power Plastic reached efficiency of 8.3%^[139] and organic tandem cells in 2012 reached 11.1%.^{[citation needed]}

The active region of an organic device consists of two materials, one electron donor and one electron acceptor. When a photon is converted into an electron hole pair, typically in the donor material, the charges tend to remain bound in the form of an exciton, separating when the exciton diffuses to the donor-acceptor interface, unlike most other solar cell types. The short exciton diffusion lengths of most polymer systems tend to limit the efficiency of such devices. Nanostructured interfaces, sometimes in the form of bulk heterojunctions, can improve performance.^[140]

In 2011, MIT and Michigan State researchers developed solar cells with a power efficiency close to 2% with a transparency to the human eye greater than 65%, achieved by selectively absorbing the ultraviolet and near-infrared parts of the spectrum with small-molecule compounds.^[141][142] Researchers at UCLA more recently developed an analogous polymer solar cell, following the same approach, that is 70% transparent and has a 4% power conversion efficiency.^{[143][144][145]} These lightweight, flexible cells can be produced in bulk at a low cost and could be used to create power generating windows.

In 2013, researchers announced polymer cells with some 3% efficiency. They used block copolymers, self-assembling organic materials that arrange themselves into distinct layers. The research focused on P3HT-b-PFTBT that separates into bands some 16 nanometers wide.^[146][147]

Adaptive cells change their absorption/reflection characteristics depending on environmental conditions. An adaptive material responds to the intensity and angle of incident light. At the part of the cell where the light is most intense, the cell surface changes from reflective to adaptive, allowing the light to penetrate the cell. The other parts of the cell remain reflective increasing the retention of the absorbed light within the cell.^[148]

In 2014, a system was developed that combined an adaptive surface with a glass substrate that redirect the absorbed to a light absorber on the edges of the sheet. The system also includes an array of fixed lenses/mirrors to concentrate light onto the adaptive surface. As the day continues, the concentrated light moves along the surface of the cell. That surface switches from reflective to adaptive when the light is most concentrated and back to reflective after the light moves along.^[148]

Incident light rays onto a textured surface do not reflect out to the air as opposed to rays onto a flat surface, but rather some light rays are bounced back onto the other surface again due to the geometry of the surface; increasing light absorption and light to electricity conversion efficiency. Surface texturing is one technique used to reduce optical losses, primarily in cost-effective, low light absorption thin-film solar cells. In combination with anti-reflective coating, surface texturing technique can effectively trap light rays within a thin film silicon solar cell. Consequently, at the same power output, thickness for solar cells can decrease with the increased absorption of light rays.

Surface texture geometry and texturing techniques can be done in multiple ways. Etching c-Si substrates can produce randomly distributed square based pyramids on the surface using anisotropic etchants.^[149] Studies show that c-Si wafers could be etched down to form nano-scale inverted pyramids. In 2012, researchers at MIT reported that c-Si films textured with nanoscale inverted pyramids could achieve light absorption comparable to 30 times thicker planar c-Si.^[150] While easier to manufacture, but with less efficiency, multicrystalline solar cells can be surface-textured through isotopic etching or photolithography methods to yield solar energy conversion efficiency comparable to that of monocrystalline silicon cells.^[151][152]

This texture effect as well as the interaction with other interfaces in the PV module is a challenging optical simulation task, but at least one efficient method for modeling and optimization that exists is the OPTOS formalism.^[153]

Solar cells are commonly encapsulated in a transparent polymeric resin to protect the delicate solar cell regions for coming into contact with moisture, dirt, ice, and other environmental conditions expected during operation. Encapsulants are commonly made from polyvinyl acetate or glass. Most encapsulants are uniform in structure and composition, which increases light collection owing to light trapping from total internal reflection of light within the resin. Research has been conducted into structuring the encapsulant to provide further collection of light. Such encapsulants have included roughened glass surfaces,^[154] diffractive elements,^[155] prism arrays,^[156] air prisms,^[157] v-grooves,^[158] diffuse elements, as well as multi-directional waveguide arrays.^[159] Prism arrays show an overall 5% increase in the total solar energy conversion.^[157] Arrays of vertically aligned broadband waveguides provide a 10% increase at normal incidence, as well as wide-angle collection enhancement of up to 4%,^[160] with optimized structures yielding up to a 20% increase in short circuit current.^[161] Active coatings that convert infrared light into visible light have shown a 30% increase.^[162] Nanoparticle coatings inducing plasmonic light scattering increase wide-angle conversion efficiency up to 3%. Optical structures have also been created in encapsulation materials to effectively "cloak" the metallic front contacts.^[163][164]

This section needs additional citations for verification. Please help improve this article by adding citations to reliable sources in this section. Unsourced material may be challenged and removed. (June 2014) (Learn how and when to remove this message)

Solar cells share some processing and manufacturing techniques with other semiconductor devices and are commonly used in calculators, watches, and to power satellites in space.^[165] However, the strict requirements for cleanliness and quality control of semiconductor fabrication are more relaxed for solar cells, lowering costs.

Polycrystalline silicon wafers are made by wire-sawing block-cast silicon ingots into 180 to 350 micrometer thick wafers. The wafers are usually lightly p-type-doped. A surface diffusion of n-type dopants is performed on the front side of the wafer. This forms a p–n junction a few hundred nanometers below the surface.

Anti-reflection coatings are then typically applied to increase the amount of light coupled into the solar cell. Silicon nitride has gradually replaced titanium dioxide as the preferred material, because of its excellent surface passivation qualities. It prevents carrier recombination at the cell surface. A layer several hundred nanometers thick is applied using plasma-enhanced chemical vapor deposition. Some solar cells have textured front surfaces that, like anti-reflection coatings, increase the amount of light reaching the wafer. Such surfaces were first applied to single-crystal silicon, followed by multicrystalline silicon somewhat later.

A full area metal contact is made on the back surface, and a grid-like metal contact made up of fine "fingers" and larger "bus bars" are screen-printed onto the front surface using a silver paste. This is an evolution of the so-called "wet" process for applying electrodes, first described in a US patent filed in 1981 by Bayer AG.^[166] The rear contact is formed by screen-printing a metal paste.To maximize frontal surface area available for sunlight and improve solar cell efficiency, manufacturers use various rear contact electrode techniques:

• Passivated emitter rear contact (PERC) uses a solid aluminum rear contact surface and adds a polymer film to capture light^[167]
• Tunnel oxide passivated contact (TOPCon) uses a grid pattern of increasingly smaller silver rear bus bars and adds an oxidation layer to the PERC film to capture more light^{[168][167][169]}
• Interdigitated back contact (IBC)^[170]

The paste is then fired at several hundred degrees Celsius to form metal electrodes in ohmic contact with the silicon. Some companies use an additional electroplating step to increase efficiency. After the metal contacts are made, the solar cells are interconnected by flat wires or metal ribbons, and assembled into modules or "solar panels". Solar panels have a sheet of tempered glass on the front, and a polymer or glass encapsulation on the back.

Different types of manufacturing and recycling partly determine how effective it is in decreasing emissions and having a positive environmental effect.^[51] Such differences and effectiveness could be quantified^[51] for production of the most optimal types of products for different purposes in different regions across time.

This section needs to be updated. Please help update this article to reflect recent events or newly available information. (November 2021)

National Renewable Energy Laboratory tests and validates solar technologies. Three reliable groups certify solar equipment: UL and IEEE (both U.S. standards) and IEC^{[citation needed]}.

The IEA's 2022 Special Report highlights China's dominance over the solar PV supply chain, with an investment exceeding US$50 billion and the creation of around 300,000 jobs since 2011. China commands over 80% of all manufacturing stages for solar panels. This control has drastically cut costs but also led to issues like supply-demand imbalances and polysilicon production constraints. Nevertheless, China's strategic policies have reduced solar PV costs by more than 80%, increasing global affordability. In 2021, China's solar PV exports were over US$30 billion.^[172]

Meeting global energy and climate targets necessitates a major expansion in solar PV manufacturing, aiming for over 630 GW by 2030 according to the IEA's "Roadmap to Net Zero Emissions by 2050". China's dominance, controlling nearly 95% of key solar PV components and 40% of the world's polysilicon production in Xinjiang, poses risks of supply shortages and cost surges. Critical mineral demand, like silver, may exceed 30% of 2020's global production by 2030.^[172]

In 2021, China's share of solar PV module production reached approximately 70%, an increase from 50% in 2010. Other key producers included Vietnam (5%), Malaysia (4%), Korea (4%), and Thailand (2%), with much of their production capacity developed by Chinese companies aimed at exports, notably to the United States.^[172]

As of September 2018, sixty percent of the world's solar photovoltaic modules were made in China.^[173] As of May 2018, the largest photovoltaic plant in the world is located in the Tengger desert in China.^[174] In 2018, China added more photovoltaic installed capacity (in GW) than the next 9 countries combined.^[175] In 2021, China's share of solar PV module production reached approximately 70%.^[172]

In the first half of 2023, China's production of PV modules exceeded 220 GW, marking an increase of over 62% compared to the same period in 2022. In 2022, China maintained its position as the world's largest PV module producer, holding a dominant market share of 77.8%.^[176]

In 2022, Vietnam was the second-largest PV module producer, only behind China, with its production capacity rising to 24.1 GW, marking a significant 47% increase from the 16.4 GW produced in 2021. Vietnam accounts for 6.4% of the world's photovoltaic production.^[176]

In 2022, Malaysia was the third-largest PV module producer, with a production capacity of 10.8 GW, accounting for 2.8% of global production. This placed it behind China, which dominated with 77.8%, and Vietnam, which contributed 6.4%.^[176]

Solar energy production in the U.S. has doubled from 2013 to 2019.^[177] This was driven first by the falling price of quality silicon,^{[178][179][180]} and later simply by the globally plunging cost of photovoltaic modules.^[174][181] In 2018, the U.S. added 10.8GW of installed solar photovoltaic energy, an increase of 21%.^[175]

Latin America: Latin America has emerged as a promising region for solar energy development in recent years, with over 10 GW of installations in 2020. The solar market in Latin America has been driven by abundant solar resources, falling costs, competitive auctions and growing electricity demand. Some of the leading countries for solar energy in Latin America are Brazil, Mexico, Chile and Argentina. However, the solar market in Latin America also faces some challenges, such as political instability, financing gaps and power transmission bottlenecks.^{[citation needed]}

Middle East and Africa: The Middle East and Africa has also experienced significant growth in solar energy deployment in recent years, with over 8 GW installations in 2020. The solar market in the Middle East and Africa has been driven by the low-cost generation of solar energy, the diversification of energy sources, the fight against climate change and rural electrification are motivated. Some of the notable countries for solar energy in the Middle East and Africa are Saudi Arabia, United Arab Emirates, Egypt, Morocco and South Africa. However, the solar market in the Middle East and Africa also faces several obstacles, including social unrest, regulatory uncertainty and technical barriers.^[182]

This section needs expansion. You can help by adding to it. (November 2021)

Like many other energy generation technologies, the manufacture of solar cells, especially its rapid expansion, has many environmental and supply-chain implications. Global mining may adapt and potentially expand for sourcing the needed minerals which vary per type of solar cell.^[183][184] Recycling solar panels could be a source for materials that would otherwise need to be mined.^[51]

Solar cells degrade over time and lose their efficiency. Solar cells in extreme climates, such as desert or polar, are more prone to degradation due to exposure to harsh UV light and snow loads respectively.^[185] Usually, solar panels are given a lifespan of 25–30 years before decommissioning.^[186]

The International Renewable Energy Agency estimated that the amount of solar panel electronic waste generated in 2016 was 43,500–250,000 metric tons. This number is estimated to increase substantially by 2030, reaching an estimated waste volume of 60–78 million metric tons in 2050.^[187]

The most widely used solar cells in the market are crystalline solar cells. A product is truly recyclable if it can be harvested again. In the 2016 Paris Agreement, 195 countries agreed to reduce their carbon emissions by shifting their focus away from fossil fuels and towards renewable energy sources. Owing to this, Solar will be a major contributor to electricity generation all over the world. So, there will be a plethora of solar panels to be recycled after the end of their life cycle. In fact, many researchers around the globe have voiced their concern about finding ways to use silicon cells after recycling.^{[188][189][190][191]}

Additionally, these cells have hazardous elements/compounds, including lead (Pb), cadmium (Cd) or cadmium sulfide (CdS), selenium (Se), and barium (Ba) as dopants aside from the valuables silicon (Si), aluminum (Al), silver (Ag), and copper (Cu). The harmful elements/compounds if not disposed of with the proper technique can have severe harmful effects on human life and wildlife alike.^[192]

There are various ways c-Si can be recycled. Mainly thermal and chemical separation methods are used. This happens in two stages^[193]

• PV solar cell separation: in thermal delamination, the ethylene vinyl acetate (EVA) is removed and materials such as glass, Tedlar®, aluminium frame, steel, copper and plastics are separated;
• cleansing the surface of PV solar cells: unwanted layers (antireflection layer, metal coating and p–n semiconductor) are removed from the silicon solar cells separated from the PV modules; as a result, the silicon substrate, suitable for re-use, can be recovered.

The First Solar panel recycling plant opened in Rousset, France in 2018. It was set to recycle 1300 tonnes of solar panel waste a year, and can increase its capacity to 4000 tonnes.^{[194][195][196]} If recycling is driven only by market-based prices, rather than also environmental regulations, the economic incentives for recycling remain uncertain and as of 2021 the environmental impact of different types of developed recycling techniques still need to be quantified.^[51]
